#version 330

// Read-only uniform values shared across all vertexes
uniform mat4 mvpMatrix;

// Incoming per-vertex values
in vec4 vVertex;
in vec2 vTexCoord0;

// Outgoing interpolated values
smooth out vec2 vTex;

void main(void)
{
	// Pass through the texture coordinates
	vTex = vTexCoord0;

	// Transform the geometry
	gl_Position = mvpMatrix * vVertex;
}

#version 330

uniform sampler2D quadTexture;
uniform int       filterNumber;
uniform vec2      tcOffset[25]; // Texture coordinate offsets

in vec2 vTex;

out vec4 vFragColour;

void main(void)
{
	// Standard
	if (filterNumber == 0)
	{
		vFragColour = texture2D(quadTexture, vTex);
	}

	// Greyscale
	if (filterNumber == 1)
	{
		// Convert to greyscale using NTSC weightings
		float grey = dot(texture2D(quadTexture, vTex).rgb, vec3(0.299, 0.587, 0.114));

		vFragColour = vec4(grey, grey, grey, 1.0);
	}

	// Sepia tone
	if (filterNumber == 2)
	{
		// Convert to greyscale using NTSC weightings
		float grey = dot(texture2D(quadTexture, vTex).rgb, vec3(0.299, 0.587, 0.114));

		// Play with these rgb weightings to get different tones.
		// (As long as all rgb weightings add up to 1.0 you won't lighten or darken the image)
		vFragColour = vec4(grey * vec3(1.2, 1.0, 0.8), 1.0);
	}

	// Negative
	if (filterNumber == 3)
	{
		vec4 texMapColour = texture2D(quadTexture, vTex);

		vFragColour = vec4(1.0 - texMapColour.rgb, 1.0);
	}

	// Blur (gaussian)
	if (filterNumber == 4)
	{
		vec4 sample[25];

		for (int i = 0; i < 25; i++)
		{
			// Sample a grid around and including our texel
			sample[i] = texture(quadTexture, vTex + tcOffset[i]);
		}

		// Gaussian weighting:
		// 1  4  7  4 1
		// 4 16 26 16 4
		// 7 26 41 26 7 / 273 (i.e. divide by total of weightings)
		// 4 16 26 16 4
		// 1  4  7  4 1

    		vFragColour = (
        	           (1.0  * (sample[0] + sample[4]  + sample[20] + sample[24])) +
	                   (4.0  * (sample[1] + sample[3]  + sample[5]  + sample[9] + sample[15] + sample[19] + sample[21] + sample[23])) +
	                   (7.0  * (sample[2] + sample[10] + sample[14] + sample[22])) +
	                   (16.0 * (sample[6] + sample[8]  + sample[16] + sample[18])) +
	                   (26.0 * (sample[7] + sample[11] + sample[13] + sample[17])) +
	                   (41.0 * sample[12])
	                   ) / 273.0;

	}

	// Blur (median filter)
	if (filterNumber == 5)
	{
		vFragColour = vec4(0.0);

		for (int i = 0; i < 25; i++)
		{
			// Sample a grid around and including our texel
			vFragColour += texture(quadTexture, vTex + tcOffset[i]);
		}

		vFragColour /= 25;
	}

	// Sharpen
	if (filterNumber == 6)
	{
		vec4 sample[25];

		for (int i = 0; i < 25; i++)
		{
			// Sample a grid around and including our texel
			sample[i] = texture(quadTexture, vTex + tcOffset[i]);
		}

		// Sharpen weighting:
		// -1 -1 -1 -1 -1
		// -1 -1 -1 -1 -1
		// -1 -1 25 -1 -1
		// -1 -1 -1 -1 -1
		// -1 -1 -1 -1 -1

    		vFragColour = 25.0 * sample[12];

		for (int i = 0; i < 25; i++)
		{
			if (i != 12)
				vFragColour -= sample[i];
		}
	}

	// Dilate
	if (filterNumber == 7)
	{
		vec4 sample[25];
		vec4 maxValue = vec4(0.0);

		for (int i = 0; i < 25; i++)
		{
			// Sample a grid around and including our texel
			sample[i] = texture(quadTexture, vTex + tcOffset[i]);

			// Keep the maximum value
			maxValue = max(sample[i], maxValue);
		}

		vFragColour = maxValue;
	}

	// Erode
	if (filterNumber == 8)
	{
		vec4 sample[25];
		vec4 minValue = vec4(1.0);

		for (int i = 0; i < 25; i++)
		{
			// Sample a grid around and including our texel
			sample[i] = texture(quadTexture, vTex + tcOffset[i]);

			// Keep the minimum value
			minValue = min(sample[i], minValue);
		}

		vFragColour = minValue;
	}

	// Laplacian Edge Detection (very, very similar to sharpen filter - check it out!)
	if (filterNumber == 9)
	{
		vec4 sample[25];

		for (int i = 0; i < 25; i++)
		{
			// Sample a grid around and including our texel
			sample[i] = texture(quadTexture, vTex + tcOffset[i]);
		}

		// Laplacian weighting:
		// -1 -1 -1 -1 -1
		// -1 -1 -1 -1 -1
		// -1 -1 24 -1 -1
		// -1 -1 -1 -1 -1
		// -1 -1 -1 -1 -1

    		vFragColour = 24.0 * sample[12];

		for (int i = 0; i < 25; i++)
		{
			if (i != 12)
				vFragColour -= sample[i];
		}
	}
}

// Set up texture sampling offset storage
const GLint tcOffsetColumns = 5;
const GLint tcOffsetRows    = 5;
GLfloat	texCoordOffsets[tcOffsetColumns * tcOffsetRows * 2];

// Calculate texture coordinate offsets for kernel convolution effects
void genTexCoordOffsets(GLuint width, GLuint height, GLfloat step = 1.0f) // Note: Change this step value to increase the number of pixels we sample across...
{
	// Note: You can multiply the step to displace the samples further. Do this with diff values horiz and vert and you have directional blur of a sort...
	float xInc = step / (GLfloat)(windowWidth);
	float yInc = step / (GLfloat)(windowHeight);

	for (int i = 0; i < tcOffsetColumns; i++)
	{
		for (int j = 0; j < tcOffsetRows; j++)
		{
			texCoordOffsets[(((i*5)+j)*2)+0] = (-2.0f * xInc) + ((GLfloat)i * xInc);
			texCoordOffsets[(((i*5)+j)*2)+1] = (-2.0f * yInc) + ((GLfloat)j * yInc);
		}
	}
}

// *** Draw the original geometry to a FBO here ***

// Now draw our full-screen quad
projectionMatrix.PushMatrix();

	projectionMatrix.LoadIdentity();
	projectionMatrix.LoadMatrix(orthoMatrix);

	modelViewMatrix.PushMatrix();

		modelViewMatrix.LoadIdentity();

		glDisable(GL_DEPTH_TEST);

		glActiveTexture(GL_TEXTURE0);
		glBindTexture(GL_TEXTURE_2D, fboTexture); // Select the texture in our framebuffer

		glUseProgram(r3dTextureProgram);
		glUniformMatrix4fv(locTexMVPMatrix, 1, GL_FALSE, transformPipeline.GetModelViewProjectionMatrix());
		glUniform1i(locTexTextureMap,       0);
		glUniform1i(locTexFilterNumber,     filterNumber);
		glUniform2fv(locTexTCOffsets,       25, texCoordOffsets); // Pass in 25 vec2s in our texture coordinate offset array

		screenQuad.Draw();

		glEnable(GL_DEPTH_TEST);

	modelViewMatrix.PopMatrix();

projectionMatrix.PopMatrix();
